Inputs
Alternator
1 X Triple High Current Connectors
• 9-32V DC Starter Battery Input(+/-)
• Ignition source connection
MPPT Solar
1 X (50A) High Current Connectors
• Minimum Solar Input Voltage: 9V DC
• Maximum Solar Input Voltage: 23V DC
• Maximum Solar Input Current: 25A
Unregulated Solar Input-utilises the inbuilt DC-DC MPPT regulator.
Not suitable for regulated solar input, connect to a standard in/out connector when
using an external or panel-mounted solar controller/regulator.
WARNING:
• Do not exceed the Maximum Voltage of 23V DC
• Do not exceed the Maximum Input Current of 25A
CONNECTIONS:
