** NOTE: Item #3 MAIN STATOR ASSEMBLY is a one-piece unit. The Stator cannot be separated from the
Generator’s outer housing.
8 – 10 – 12 KW “MB” BRUSH TYPE GENERATOR ASSEMBLY
DESCRIPTION PART NUMBER
8KW 10-12KW
1. COVER SCREEN 02SCREENKUB 02SCREENKUB
2. BEARING PLATE 02BRPLKUBM 02BRPLKUBM
3. STATOR ASSEMBLY ** 02MN8KBM 02MN12KBM
4. ROTOR BEARING 02BRG6206 02BRG6206
5. BRUSH SET 02BRU7004M 02BRU7004M
6. ROTOR ASSEMBLY 02RTR8KBM 02RTR12KBM
GENERATOR ASSEMBLY 02GEN8KBM 02GEN12KBM
2
