OPERATING INSTRUCTIONS RC30 & RC23
Specifi cations
Various load conditions will affect winch performance. The line pull required for a specifi c application de-
pends on the weight of the load, condition of the trailer rollers, and the degree of the loading ramp incline.
The chart below is based on a single line pull and is a guideline to aid in calculating pulling requirements.
NOTE: The noise level of this winch in operation is below 98db (A).
CHART #1 - Approximate Rolling Load Capacities. (Values are in pounds)
CHART #2 - Winch and Boat Capacities
% Incline Level Surface 5% 10% 20% 30% 50% 70% 100%
Deg Incline 0 DEG 3 DEG 6 DEG 11 DEG 17 DEG 26 DEG 35 DEG 45 DEG
RC23 24000 13340 10040 6800 5220 3720 3060 2580
RC30 40000 23345 17570 11900 9135 6510 5355 4515
- A 10% incline (or 6 deg) is 1 foot rise in 10 feet.
- To convert from pounds to kilos divide by 2.2
- Capacity can be increased (almost doubled) by using a pulley block.
Model Single Line
Capacity
Double Line Pull Approximate*
Boat Weight
Approximate*
Boat Size
RC23 2400 lbs 4300 lbs 7500 lbs 17-23 ft
RC30 4000 lbs 7500 lbs 11500 lbs 23-30 ft
* Boat size and weight is approximate and varies depending on boat type. When calculating boat weight be
sure to use fully loaded weight- including boat, motor, fuel, water, gear etc.
Model Line Speed
@ Capacity
(FPM)
Gear
Ratio
Voltage
(Volts)
Circuit
Breaker
(Amps)
Unit
Weight
(lbs)
Depth Height Width
RC23 14 225:01:00 12 60 X XX XXX XXXX
RC30 8 450:01:00 12 60 X XX XXX XXXX
CHART #3 - Winch Specifi cations
