There are two sensors inside the encoder and each one is represented by the
LEDs ECA1, ECB1, ECA1 and ECB2. Each one ashes according to the corre-
sponding position of the disc.
2.5 – CONNECTING THE “TRV” ELECTROMAGNETIC LOCK
If one decides to use an (optional) electromagnetic lock, one mu󰍰 connect the
“Optional Relay Module” to this connector. The control unit will also recognize
the module automatically and a time interval (used to 󰍰art the opening move-
ment of the operator after activating the electromagnetic lock) will be added.
2.6 – CONNECTING THE “LUZ” COURTESY LIGHT
If one decides to use courtesy light, one mu󰍰 connect the “Optional Relay
Module” to this connector. By doing so, the operation of the courtesy light
is always enabled.
One mu󰍰 set the desired time through the DIP switch.
2.7 – CONNECTING THE “RX” LOOSE RECEIVER
A loose receiver can be added to the control unit through the “RX” connector.
CAUTION: Before connecting the optional accessories (Electromag-
netic lock and/or Courtesy Light / Traffic Light (Visual Exit Annunciator),
pushbuttons etc), we strongly recommend testing the general opera-
tion of the product. To do so, send a command to the operator to start
the self-learning cycle.
2.8 – "FOT" CLOSING PHOTOCELL CONNECTION
This is a dedicated input port for the 'closing photocell', which is a sensor that
detects an ob󰍰acle during the gate's closing cycle, preventing the gate to
move if there is an ob󰍰acle along its course. If there is a blockage during the
closing cycle, the operator reverses its movement to the opposite direction.
The photocells should be in󰍰alled about 50 cm (1.65 ft) above the ground (in
accordance with the manufacturer's recommendation), in such a way that the
both the transmitter and the receiver are aligned between each other. The
electrical connections mu󰍰 be as follows:
Terminal block 2: 15V (positive "+");
Terminal block 1: GND (negative "-");
Terminal block 3: FOT (Contact of the Photocell).
2.9 – "FAB" OPENING PHOTOCELL CONNECTION
This is a dedicated input port for the 'opening photocell', which is a sensor
that detects an ob󰍰acle during the gate's opening cycle, preventing the gate
to move if there is an ob󰍰acle along its course. If there is a blockage during
