Table 8.2
Resolution & Unit
Option
Range (Min. to Max.)
Type J (Fe-K)
Type K (Cr-Al)
Type T (Cu-Con)
0.0 to +960.0°C / +32.0 to +1760.0°F
Type R (Rh-13%)
Type S (Rh-10%)
Type B
Type N
0 to 20 mA
4 to 20 mA
0 to 80 mV
0 to 1.25 V
0 to 5 V
0 to 10 V
1 to 5 V
RTD Pt100
-30000 to 30000 units
-199 to +600 °C / -328 to +1112 °F
or
-199.9 to +600.0 °C / -328.0 to +1112.0 °F
1 Unit
0.1 Unit
0.01 Unit
0.001 Unit
1 °C /°F
or
0.1 °C /°F
1°C
or
0.1 °C
Reserved for customer specific Thermocouple type not listed above. The
type shall be specified in accordance with the ordered (optional on request)
Thermocouple type.
-30000 to 30000 units
Reserved
-200.0 to +1376.0°C / -328.0 to +2508.0°F
-200.0 to +387.0°C / -328.0 to +728.0°F
0.0 to +1771.0°C / +32.0 to +3219.0°F
0.0 to +1768.0°C / +32.0 to +3214.0°F
0.0 to +1826.0°C / +32.0 to +3218.0°F
0.0 to +1314.0°C / +32.0 to +2397.0°F
