VIALITEHD-BLUE2-LINK-HANDBOOK-HRX-XX-8X-35-XXXXX
5
1 Introduction
The ViaLiteHD RF Fibre Optic Links (FOLs) are a family of fibre optically coupled link systems
designed for the transmission of RF analogue signals over long distances for the communications
market. ViaLiteHD is a product brand manufactured by Pulse Power and Measurement Ltd (PPM).
ViaLite Communications is a division of Pulse Power and Measurement Ltd (PPM).
This handbook covers the following ViaLiteHD RF Link part numbers:
1.1.1 HRX-L1-8P-33-S1310
L-Band HTS (700-2450 MHz) Transceiver with 50 ohm SMA and SC/APC connectors
1.1.2 HRU-G1-8P-10-S1310
GPS Dual Transmitter, 50 ohm SMA, internal antenna PSU and SC/APC connectors
1.1.3 HRU-L3-8P-35-W1310-1550
L-Band HTS (700-2450 MHz) Dual Transmitter with WDM, 75 ohm F-type and SC/APC connectors
1.1.4 HRV-L3-8P-03
L-Band HTS (700-2450 MHz) Dual Receiver with 75 ohm F-type and SC/APC connectors
For complete information and product familiarisation, this handbook should be read in conjunction
with all other relevant handbooks for your ViaLiteHD system.
1.2 Blue2 Link
ViaLite‘s RF over fibre Blue2 Link is a dual-solution OEM which can be setup as 2x transmitters,
2x receivers or a transceiver, as required. The link is available in all ViaLite frequency bands
from 2 kHz-4.2 GHz, including ViaLite‘s extended L-Band HTS. (see the relevant characterisation
data in section 3).
1.3 Typical deployment
A typical system operates as follows.
The new Blue2 Link s a small dustproof module available in all ViaLiteHD RF bands. It can be
either a dual transmitter, dual receiver or a transceiver.
The link is available with two optical inputs/outputs or single optical input/output if the integral
WDM module option is selected.
The 15 way D-type connector is used for serial data transmission (RS232, RS485 & TTL), Tx or
Rx Alarms, I2C set up using the ViaLiteHDProgramming Kit (HRxHD-DEV103) and for
connecting an external power supply (optional HPS-CS-4).
Applications include:
Martitme
Satcom
Broadcast
GPS
