PR electronics 5531 - Technical Specifications; Environmental Conditions; Mechanical Specifications; Common Electrical Specifications

5531V105-UK 7
Technical specifications
Environmental conditions:
Specifications range .................................... -20°C to +60°C
Storage temperature ................................... -20°C to +60°C
Calibration temperature............................... 20...28°C
Relative humidity ......................................... <95%RH(non-cond.)
Protection degree, from front ...................... IP65
Mechanical specifications:
Dimensions(HxWxD),5531A,5531B .......... 48 x 96 x 120 mm
Cut-outdimensions(HxW) .......................... 44.5 x 91.5 mm
Weightapprox.,5531A,5531B ................... 200 g
Dimensions(HxWxD),5531B1,5531B2 ..... 92 x 112 x 143 mm
Cable glands / cable diameter .................... 2x M16 x 1.5 / Ø 5...8 mm
Dimensions, 8501 backplate ....................... 112 x 112 mm
Weightapprox.,5531B1,5531B2 ............... 900 g
Wiresize,connectorterminal1-4 ............. 0.13...2.08 mm
2
/
 AWG26...14strandedwire
Screw terminal torque ................................. 0.5 Nm
Common electrical specifications:
Supply ......................................................... Input loop-powered
Signal / noise ratio ...................................... > 60 dB
Response time (0...90%, 100...10%) .......... < 1 s
Updating time .............................................. 500 ms
Input and output specifications:
Input range .................................................. 4...20 mA
Measurement range .................................... 3.6...23 mA
Input voltage drop, without backlight ......... < 1.5 V @ 20 mA
Input voltage drop, with full backlight ......... < 10.5 V @ 20 mA
Loop error detection, 4...20 mA:
Low detection (InLo) ............................... ~ < 3 mA
 Highdetection(InHi) ............................... ~ > 24 mA
Display readout ........................................... ± 9999 (4 digits)
Digit height .................................................. 16 mm
Accuracy values
Input
Absolute
accuracy
Temperature
coefficient
4...20 mA ≤ ±0.1% of span ≤ ±0.01% of span / °C
EMC immunity influence .................................. < ±0.5% of span
