10 5725V102-UK
Common electrical specifications:
Supply voltage, universal ..................................... 21.6...253 VAC, 50...60 Hz
or 19.2...300 VDC
Power consumption, 5725A / 5725D ............. < 2.8 W / < 3.6 W
Isolation voltage, test / operation .................... 2.3 kVAC / 250 VAC
Signal / noise ratio .................................................. > 60 dB
Input specifications:
Frequency range,
f/I conversion function ................................ 0.001 Hz to 50 kHz
Low cut off frequency (default value) ............ 0.0009 Hz
Low cut off frequency, (LCOF=YES) ................. 0.5 Hz (2 s)
Max. frequency, with input filter ON ............... 50 Hz
Time range, period time function ................... 999.9 s to 20 µs
Low cut off period time ........................................ 1111 s
Min. period time with input filter ON .............. 20 ms
Response time (0...90%, 100...10%) ................. < 1 period + 100 ms
Input types:
NAMUR input - acc. to EN 60947-5-6:
Trig-level LOW ........................................................... ≤ 1.2 mA
Trig-level HIGH .......................................................... ≥ 2.1 mA
Input impedance ...................................................... 1 kΩ / < 1.5 nF
Breakage detection ................................................. ≤ 0.1 mA
Short-circuit detection ........................................... ≥ 6.9 mA
Sensor supply - pin 44, fixed .............................. 8.3 V
Accuracy values
Specification
Absolute
accuracy
Temperature
coefficient
Input to Display & Relays ≤ ±0.05%
≤ ±0.01% / °C
Input to Analog Output ≤ ±0.1%
EMC immunity influence ...................................................... < ±0.5% of span
Extended EMC immunity:
NAMUR NE 21, A criterion, burst ..................................... < ±1% of span
