7 Operation
32
220/230/240V AC Outlets
The Outlets are used to power 220/230/240V Single Phase 50Hz loads requiring
up to continuous power. This socket is only corresponding to a client, the different
laws and regulations according to the sales area changes corresponding to the
socket.
Ground Terminal
The Ground (Earth) terminal is used to ground the generator when grounded
electrical devices are being used. Consult an electrician for local grounding
regulations.
Parallel Connection within 2 generator
See the parallel Kit Operator’s Manual
NOTE: All connections to parallel kit should be made while both inverters are
turned off and loads disconnected
1. Make sure the Economy throttle is in the same position on both generators
2. Make appropriate parallel connections to the outlets on each inverter as
outlined in the owner’s manual supplied with the kit.
NOTE: Do not disconnect any parallel kit connections once the units are running
3. Start both units per starting instructions. Once the green output indicator
illuminates, devices can be connected and turned on using the parallel kit
outlet.
4. Follow Stopping the engine instructions
NOTE: Only use Pramac approved parallel kit
