Signal-to-Noise Ratio 110 dB
Total Harmonic Distortion (1 kHz, 1 VRMS) 0.002%
Boost/Cut Range
±
15 dB
Equalizer Center Frequencies and Q Values:
Band Frequency Q Value
Sub (30 - 66 Hz) 2.0 - 3.0
Low (90 - 300 Hz) 3.0 - 5.5
Low-Mid (430 - 900 Hz) 2.5 - 4.5
High-Mid (950 Hz - 4.6 kHz) 2.5 - 6.0
Treble (6 - 16 kHz) 1.3 - 3.3
Maximum Input Voltage (Flat) 10 VRMS
Maximum Output (10 k
Ω
Load) 10 VRMS
Frequency Response 3 to 100 kHz
Supply Voltage 9 - 15 VDC
Dimensions 4.60" L
6.75" W
0.95" H
FEATURES / SPECIFICATIONS
1
5 Band Parametric Equalizer
Preamp Line Driver
Choice of 16 Selectable Frequency/Q
Settings for Each Band
Front and Rear Outputs with Fader Control
Dual Selectable Illumination
Center-Detented Boost/Cut Controls
±15 dB Boost/Cut for Each Band
Defeat Switch
Gold-plated RCA Input and Output Connectors
PWM (Pulse Width Modulated) Power Supply
Independent L & R Input Gain Adjustments
Input Clip Indicator
Designed and Handcrafted in the U.S.A.
