Rules for Safe Operation
The following safety precautions are suggested. This Trailer Dump Cart is designed, engineered and tested to
offer reasonably safe and effective service, provided that it is operated in strict accordance with these
instructions. Failure to do so may result in personal injury. Always observe the rules of safe operation. Please
read and retain this manual.
• Read and understand your tractor’s owner’s manual and towing safety rules, know how to operate you
tractor before using any attachment.
• Do not allow anyone to ride or sit on tow behind equipment during operation.
• Be alert for holes in the terrain and other hazards. This could cause you to lose control of the cart and
lawn tractor.
• Follow maintenance and lubrication instructions as outlined in this manual.
• Tractor braking and stability may be affected with the attachment of this unit. Be aware of changing
conditions on slopes. Refer to safety rules in your tractor owner’s manual concerning safe operation on
slopes. Stay Off Steep Slopes.
• Always operate up and down a slope, never across the face of a slope.
• Do not drive close to creeks, ditches or public highways.
• Always wear substantial footwear. Do not wear loose fitting clothing that may get caught in moving parts.
• Avoid extremely sharp turns.
• Follow the maintenance instructions as outlined in this owner’s manual.
• Do not exceed maximum towing speed of 3-4 M.P.H.
• Maximum Carrying Capacity 750 Lbs.
• Warning of danger of improper use of the Trailer Dump Cart. This unit is intended for use only
with Riding Mowers or Garden Tractors. It is definitely not for Highway use, being pulled at high speeds,
or transporting passenger(s) of any sort. Such use could result in injuries for which we cannot be held
responsible.
Carton Contents
1
4
3
2
6
7
5
8
9
Ref. Qty. Description
1
2
3
4
5
6
7
8
9
1
1
1
1
1
1
1
2
2
Body
Tow Bar
Clevis Plate
Undercarriage Axle Support
Axle
Pedestal
Latch
Wheels
1” x 1” Tube Plug
7
Ref
No.
Qty. Description Part No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
1
1
2
2
1
6
1
1
1
1
1
1
4
Body
Tow Bar
Axle
Wheel
Cotter Pin
Tailgate
3/4” Flat Washer
Pedestal
Undercarriage
Clevis Plate
Latch
1/4” x 2 3/4” Spacer
Spring
5/16” x 3/4” Truss Head Bolt
5033TB
4631P
1252
4568C
1262
4560-2TB
1264
4630B
4556B
1243P
1265P
4468
4497
1586
Ref
No.
Qty. Description Part No.
15
16
17
18
19
20
21
22
23
24
25
8
8
2
6
8
6
1
1
1
1
2
3/8” x 3/4” Truss Head Bolt
3/8” Hex Head Nut
5/16” x 3/4” Hex Head Bolt
5/16” Hex Head Nut
3/8” Lock Washer
5/16” Lock Washer
1/4” x 3-1/2” HH Bolt Grade 8
1/4” NyLock Nut
1/2” x 1-3/4” Hitch Pin
#14 Clevis Pin Clip
1” x 1” Tube Plug
4552
1273
1248
1275
1274
1276
1645
1558
1840
1042
2176
4
15
5
7
9
6
1
14
10
3
23
17
11
8
13
18
20
18
24
20
2
19
21
16
25
22
16
12
