STEP 1
Attach one Ground Frame ASSY (#2) to Rear Main Frame ASSY (#1), using:
two M12*85 SHCS (#32)
two Φ13*Φ26*2 Flat Washer (#41)
two Φ12 Spring Washer (#42)
Note: No Need To Tighten Bolts.
Assembly
20
