Precor GluteBuilder GPL724/D45HE - Page 7

7
Exploded View and Parts List
Overall
Item No. Part No. Description QTY
24 BB-PL5000V1 Aluminium Cap Φ49*Φ12.5*10 1
25 PKB2000 Aluminium Cap Φ63*Φ12.5*10.5 4
26 GB70M8*30*30DY20 Socket Head Cap ScrewM8*30 2
27 GB70M10*25DY20NL Socket Head Cap ScrewM10*25 3
28 GB70M10*25DY20 Socket Head Cap ScrewM10*25 8
29 GB70M12*75DY20 Socket Head Cap ScrewM12*75 2
30 GB70M10*60DY20 Socket Head Cap ScrewM10*60 1
31 GB70M12*85DY20 Socket Head Cap ScrewM12*85 8
32 GB70M12*145DY20 Socket Head Cap ScrewM12*145 7
33 GB70M12*150DY20 Socket Head Cap ScrewM12*150 1
34 CNLM10*25DY20NL Flat Head Cap ScrewM10*25 5
35 PNLM10*25DY20NL Button Head Cap ScrewM10*25 4
36 PNLM12*25DY20NL Button Head Cap ScrewM12*25 3
37 NM8DY2 Nylon Lock Nut M8 2
38 NM10DY2 Nylon Lock Nut M10 1
39 NM12DY2 Nylon Lock Nut M12 14
40 DQ10DY2A Flat Washer Φ11*Φ23*2 15
41 DQ12DY2B Flat Washer Φ13*Φ26*2 32
42 GB9312DY12 Spring Washer Φ12 4
43 NBS6DHS Hex Key S=6 1
44 NBS8DHS Hex Key S=8 1
45 NBS10DHS Hex Key S=10 1
