Engine Parts List
Part Description Qty.
1A Starter Assembly 1
2A Screw M5 x 20 7
3A Starter Gasket 1
4A Start Claw 2
5A Start Spring 2
6A Start Reel 1
7A Stop Ring 2
8A Start Reel Assembly 1
9A Oil Seal 1
10A Rear Crankcase 1
11A Crankcase Gasket 1
12A Bearing 6202/P6 2
13A Crankshaft/Connecting Rod Assembly 1
14A Key 3 x 5 x 13 1
15A Pin 4 x 10 4
16A Front Crankcase 1
17A Screw M4 x 12 1
18A Screw M5 x 30 4
19A Engine Fan 1
20A Washer Ø8 1
21A Lock Washer Ø8 1
22A Nut M8 1
23A Ignition Coil 1
24A Cord Component 1
25A Flat Washer 2
26A Expander 1
27A Wave Spring Washer 2
28A Screw Pin 2
29A Fan Cover 1
30A Oil Seal 1
31A Screw M5 x 25 6
32A Connecting Rod Bearing 1
33A Piston Pin Circlip 2
34A Piston 1
35A Piston Pin 1
36A Piston Ring 2
Part Description Qty.
37A Cylinder Gasket 1
38A Cylinder 1
39A Screw M5 x 20 4
40A Engine Housing 1
41A Spark Plug 1
42A Spark Plug Spring 1
A43 Gasket 1
A44 Spark Plug Cap 1
45A Plug 1
46A Top Cover 1
47A Insulation Gasket 1
48A Muffler Gasket 1
49A Muffler Assembly 1
50A Muffler Cover 1
51A Screw M5 x 12 2
52A Screw M6 x 60-12.9 2
53A Air Intake Pipe Gasket 1
54A Air Intake Pipe 1
55A Carburetor Gasket 1
56A Carburetor Assembly 1
57A Air Cleaner Housing 1
58A Screw M5 x 50 2
59A Filter Plate 1
60A Air Filter 1
61A Air Cleaner Cover 1
62A Fuel Tank Stand 1
63A Rubber Cover 1
64A Fuel Filter 1
65A Fuel Inlet Pipe 1
66A Seal Plug 1
67A Fuel Return Pipe 1
68A Screw M5 x 16 2
69A Fuel Tank 1
70A
Fuel Tank Cap Assembly 1
71A
Rubber Washer 2
72A
Carburetor Cover 1
When ordering replacement parts from this list, the “A” suffix must be included in order to get the correct part.
