Page 22 For technical questions, please call 1-888-866-5797. ITEM 58169
SAFETY SETUP OPERATION MAINTENANCE
Parts Lists and Diagrams
Main Parts List
Part Description Qty.
1 Handle Grip 2
2 Throttle Lever 1
3 Circlip Ø3.5 1
4 Torsion Spring 1
5 Throttle Bracket 1
6 Screw St4.8 x 19 1
7 Switch Assembly 1
8 Pin 1
9 Throttle Cable Assembly 1
10 Connector Wire 1
11 Right Handle 1
12 Middle Handle 1
13 Left Handle 1
14 Capscrew M8 x 45 8
15 Handle Knob M8 8
16 Tie Strap 5
17 Lower Handle 1
18 Bolt M8 x 150 2
19 Switch Cover 1
20 Flange Lock Nut M8 2
21 Screw M6 x 16 2
22 Screw M6 x 12 2
23 Washer Ø6 2
24 Wheel 2
25 Axle / Drag Bar Assembly 1
26 R-Clip Ø3 1
27 Bracket Assembly 1
28 Bolt M6 x 35 2
29 Clevis Pin 8 x 18 1
30 Flange Lock Nut M6 2
31 Nut M8 1
32 Clutch Drum 1
33 Roller Bearing 629-2rs 1
34 Worm Shaft Flange Bushing 1
35 Needle Roller Thrust Bearing 1
Part Description Qty.
36 Bearing Thrust Reducer 1
37 Worm Gear Shaft 1
38 Washer 1
39 Needle Roller Bearing 1
40 Seal Washer 2
41 Bolt M6 x 10 2
42 Tine Assembly D 1
43 Tine Assembly C 1
44 Bolt M6 x 20 6
45 Left Gear Housing 1
46 Right Gear Housing 1
47 Tine Assembly B 1
48 Tine Assembly A 1
49 R-Clip 2
50 Dust Cap 2
51 Fiber Washer 2
52 Seal FB 19 x 32 x 6.5 2
53 Tine Shaft Flange Bushing 2
54 Washer 2
55 Drive Gear 1
56 Tine Shaft 1
57 Rear Tine Shield 1
58 Washer Ø8 8
59 Lock Washer Ø8 8
60 Bolt M5 x 16 2
61 Lock Nut M5 2
62 Front Tine Shield 1
63 Lock Washer Ø6 4
64 Bolt M6 x 40 4
65 Throttle Cable Housing 1
66 Combined Tine Shaft /Gear Assembly 1
67 Engine 1
68 Transmission Assembly 1
69 Cross Bar 1
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 193175433749 when ordering parts.
