Page 30 For technical questions, please call 1-888-866-5797. ITEM 61594
SAFETY OPERATION MAINTENANCESETUP
Engine Parts List
Part Description Qty
1 Gasket, Cylinder Head 1
2 Cover Subassembly, Cylinder Head 1
3 Gasket, Cylinder Head Cover 1
4 Tube, Breather 1
5 Bolt 4
6 Stud 1
7 Stud 1
8 Stud 2
9 Pin 2
10 Bolt, Cylinder Head 4
11 Plug, Spark 1
12 Head Subassembly, Cylinder 1
13 Crankcase Subassembly 1
14 Sensor, Engine Oil 1
15 Gear Assy, Governor 1
16 Arm, Governor 1
17 Bolt, Drain Plug 2
18 Washer 2
19 Bearing 1
20 Seal, Oil 1
21 Washer 1
22 Pin 1
23 Bolt 2
24 Cover, Crankcase 1
25 Bearing 1
26 Seal, Oil 1
27 Gasket, Crankcase 1
28 Pin 2
29 Dipstick Subassembly, Oil 1
30 Plug Subassembly, Engine Oil 1
31 Bolt 6
32 Crankshaft Assy. 1
33 Clip, Piston Pin 2
34 Piston 1
35 Pin, Piston 1
36 Rod, Connecting 1
37 Ring, Primary 1
38 Ring, Secondary 1
39 Ring Set, Oil 1
40 Camshaft Assy. 1
41 Valve, Exhaust 1
42 Valve, Intake 1
43 Seat, Valve Spring 1
44 Retainer, Exhaust Valve 1
45 Rotator, Valve 1
46 Guide, Seal 1
47 Tappet, Valve 2
48 Lifter, Valve 2
49 Plate Subassembly, Lifter Stopper 1
50 Bolt, Valve Adjusting 2
51 Rocker, Valve 2
Part Description Qty
52 Nut, Valve Adjusting 2
53 Nut, Valve Lock 2
54 Spring, Valve 2
55 Starter Assy, Recoil 1
56 Bolt 3
57 Shroud 1
58 Shroud, Cylinder Body 1
59 Shield,Lower 1
60 Protector, Oil 1
61 Switch Subassembly, Stop Engine 1
62 Bolt 2
63 Bolt 1
64 Collar 1
65 Bolt 1
66 Bolt 4
67 Carburetor Assy. 1
68 Gasket, Air Cleaner 1
69 Gasket, Carburetor 1
70 Plate, Carburetor Insulator 1
71 Gasket, Carburetor Insulator 1
72 Nut 2
73 Cleaner, Air 1
74 Jacket, Rubber 1
75 Gasket, Exhaust Outlet 1
76 Nut 2
77 Muffler Assy 1
78 Tank, Fuel 1
79 Strainer, Fuel 1
80 Cover, Fuel Tank 1
81 Outlet Subassembly, Fuel Tank Oil 1
82 Clamp 3
83 Tube, Fuel 1
84 Bolt 1
85 Nut 2
86 Nut, Flywheel 1
87 Pulley,Starter 1
88 Impeller 1
89 Flywheel Subassembly 1
90 Bolt 2
91 Coil, Ignition 1
92 Control Assy, Throttle 1
93 Bolt 2
94 Spring, Governor 1
95 Rod, Governor 1
96 Spring, Throttle Valve Returning 1
97 Bolt, Governor Support 1
98 Nut 1
99 Support Subassembly, Governor 1
100 Valve, One Way 1
101 Clamp 1
102 Hose, Fuel Steam Rubber 1
To Next Page
