Page 17R&(%$*4.8"4,7%T'*#$"&8#Q%/7*,#*%4,77%=>???>?AA>UVBV1ITEM 63406
MDR6LIM6LC[J[6PDLGJEKDGEL6EDE<6
['5/%L(&'+7*#.&&$"83
[(&+7*5 [&##"+7*%<,'#*# H"d*7O%M&7'$"&8#
Pump overheats
1. Incorrect lubrication or
not enough lubrication.
2. Worn parts.
1. Lubricate using recommended oil or
grease according to directions.
2. Have qualified technician inspect internal
mechanism and replace parts as needed.
Unit stalls
1. Low engine speed.
2. Severely clogged air filter.
3. Improper lubrication.
1. Qualified technician should increase no load speed
to 3,800±100 RPM by adjusting pressure switch.
2. Replace air filter.
3. Check for proper oil level.
Pump does not
pump water
1. Pump is not primed.
2. Intake Strainer clogged.
3. Air leak at intake connector.
4. Hose leaks.
5. Suction hose has
collapsing wall.
6. Hose has too small diameter.
7. Pump is too high above
water surface.
1. Prime Pump.
2. Clean Intake Strainer or replace if damaged.
3. Replace Coupling Gasket or tighten clamp.
4. Replace hose.
5. Use hose with non-collapsible wall.
6. Use hose with diameter 3" or greater.
7. Locate Pump at a lower level so it doesn’t
have to work so hard to lift the water.
Low Pump Output
1. Suction hose collapsed,
damaged, too long or
diameter is too small.
2. Air leak at connector.
3. Strainer clogged.
4. Discharge hose damaged, too
long or diameter too small.
1. Replace or adjust suction hose.
2. Replace Coupling Gasket or tighten Clamp.
3. Clean Strainer.
4. Replace or adjust Discharge Hose.
R&77&)%,77%#,2*$O%/(*4,'$"&8#%).*8*S*(%9",38&#"83%&(%#*(S"4"83%$.*%*T'"/5*8$%&(%*83"8*1
d. Pull Starter Handle to distribute oil in cylinder.
Stop after one or two revolutions when you
feel the piston start the compression stroke
(when you start to feel resistance).
4. ]DLL6PI-%
Disconnect battery cables (if equipped).
Recharge batteries monthly while in storage.
5. MLJPDX6%DP6D-%
Cover and store in a dry, level, well-ventilated
area out of reach of children. Storage area
should also be away from ignition sources, such
as water heaters, clothes dryers, and furnaces.
EJLG<6- For every 3 months of an extended
storage period, the pump must be connected to a
water supply, primed, started, and allowed to run
for 15 – 20 minutes or the Warranty is VOID.
6. DRL6P%MLJPDX6-%
Before starting the engine after storage, keep in
mind that untreated gasoline will deteriorate quickly.
Drain the fuel tank and change to fresh fuel if
untreated gasoline has been sitting for a month,
if treated gasoline has been sitting beyond
the fuel stabilizer’s recommended time
period, or if the engine does not start.
