Predator PH16-71 - Base Cover Removal

Disassembly Procedures 1-7
Base Cover Removal 0
1. Remove ten (10) screws from the base cover (Figure 1-3).
Figure 1-3. Base Cover Removal
2. Carefully pry up the base cover from the upper side to release the latches as shown in
Figure 1-4.
Figure 1-4. Base Cover Removal
