PREMIUM STRINGER 8900 Electro - String Clamp Adjustments (Appendix A); Adjusting String Clamp Holding Pressure

15
APPENDIX A
ADJUST STRING CLAMP TO THE CORRECT HOLDING PRESSURE
* If gripper of the string clamp is over tension, lift the clamp handle up and
turn the round adjustment of the string clamp counterclockwise to the correct
tension by needle nose pliers or fingers adjusting directly.
*If gripper of the string clamp doesn’t hold string well, lift the clamp handle up
and turn the round adjustment of the string clamp clockwise to the correct
tension by needle nose pliers or fingers adjusting directly.
Needle Nose Pliers Adjustment
Lift up the handle Rotate the adjustment
Fingers Adjustment
Lift up the handle Rotate the adjustment
1
.
2
.
1
.
2
.
