Premium PAC12040A - Parts Names

Indoor Unit
Note:
1.If the power supply from outdoor unit, you can find the power supply card is
fitted in the outdoor unit.
2.
.
The descriptions in this user manual text and figures may have slight
difference to the promotion information and actual appliance. Please refer to
the real appliance purchased, Thank you
Parts Names
Indoor Unit
Outdoor Unit
1 Front panel
2 Air filter
3 Handling switch
4 Louver
5 Signal receptor
6 Supply cord
7 Remote controller
8 Drain hose
9 Refrigerant gas/
liquid pipe
10 Cut-off valve
11 Air outlet cover
Outdoor Unit
Air inlet
Air outlet
Air inlet
Air outlet
5
12
3
4
6
7
8
9
10
11
3
