Parts List of Outdoor unit
No. Name Quantity Remark
1 Condenser 1
2 Top cover board 1
3 Capillary assembly for system B 1
4 Capillary assembly for system A 1
5 Compressor connecting line for system A 1
6 Compressor connecting line for system B 1
7 Grille assembly 1
8 Rubber supporter 4
9 Right-hand board 1
10 Partition plate 1
11
Electrical box cover board 1
12 Compressor discharge tube for system A 1
13 Compressor air return tube for system A 1
14 Compressor accessory for system A 1
15 Compressor capa
citor for system A 1
16 Clamp for ca
pacitor 2
17 Compressor capa
citor for system B 1
18 Fan motor capa
citor 1
19 Tr
ansformer 1
20 Outdoor controller main board 1
21 Three sockets
terminal board 1
22 Tw
o sockets terminal board 2
23 Main board holder 5
24 Electrical box 1
25 Compressor for system
A 1
26 Compressor cushion for system A 3
27 Bolt 8
28 Small valve for system B 1
29 Big valve for system B 1
30 Small valve for system
A 1
31 Big valve for system
A 1
32 Va
lve plate 1
33 Chassis assembly 1
34 Compressor cushion for system B 3
35 Compressor for system
B 1
36 Compressor air return tube for system B 1
37 Big gasket 6
38 Six-angle nu
t 6
39 Compressor discharge tube for system B 1
40 Fan motor holder asse
mbly 1
