11.
Refit the bracket fitting the bottom
hinge pin. Replace both adjustable feet.
Transfer the lower door to the property
position.
Screw
12. Make the middle hinge reverse the
direction 180°C, then transfer it to the
left property position. Make the middle
hinge pin in the upper hole of the lower
door, then tight the bolts.
Ensure the freezer door is aligned
horizontally and vertically, so that the
seals are closed on all sides before
finally tightening the hinge.
13. Place the upper door back on. Ensure
the fridge door is aligned horizontally and
vertically so that the seals are closed on
all sides before finally tightening the top
hinge.
14. Insert the hinge bracket and screw it
to the top of the unit.
15.
Use a spanner to tighten it if necessary.
16.
Put the top cover and then screw back.
17.
With the doors closed, check that the
doors are aligned horizontally and
vertically and that the seals are closed on
all sides before finally tightening the
bottom hinge. Re-adjust the levelling feet
as needed.
screw
screw
