MAIN COMPONENTS 220V
OPERATION:
The water heater works off of the starboard engine cooling system + On the 220 V circuit.
WATER HEATER 220V
Location: Engine compartment
1. 220V socket
2. Water heater - 25 litre
3. Thermostatic mixer valve
SUPPLY VALVE - WATER HEATER / ENGINE
Location: Engine compartment
This valve allows you to isolate a faulty circuit
8
ELECTRICAL EQUIPMENT
