AIR CONDITIONING
LAYOUT OF COMPONENTS
220V socket
(Reference 1)
Compressor - Saloon
(Reference 2)
Master switch
(Reference 3)
Seawater inlet
(Reference 4)
Maintenance of filters (to
engage in regular):
- Close valves taken
seawater.
- Unscrew the top of the filter.
- Clean the strainer.
- Put everything back in place.
A. Bipolar circuit breaker
B. Differential circuit breaker
C. Relay box
(Reference 5)
Drainage - Compressors
(Reference 6)
Compressor - Forward
cabin
(Reference 7)
Control
WARNING
Refer to the manufacturer's instructions for use and maintenance.
