16/118
GAS SYSTEM
LOCATION OF GAS VALVE
A pictogram helps to locate it
easily
Valve
REF Designation
6 Open valve
7 Closed valve
WARNING
- For all recommendations concerning gas: Refer to chapter 2, «Safety».
- Don't use a solution containing ammonia.
- Don't use a flame to detect leaks.
- Don't smoke, don't use a naked flame when you change the gas cylinder.
