64/118
SEWAGE TANK
Location: Under the passageway
Capacity: 120 l
WARNING
- The tanks' nominal capacity cannot be fully used due to the load and the
need to maintain the correct trim. A 20% reserve should be kept.
SYSTEM DIAGRAM OF EXCREMENT TANK
1. Filler cap (Deck drainage)
2. Thru-hull fitting - elbowed
3. Inspection hatch
4. Electrical gauge
5. Elbowed plunger
6. Elbowed plunger
7. Masher
8. Sewage tank
