Reversing the doors
If access is restricted, you can reverse the doors by following the instructions below.
Remove the power plug from the wall outlet and open both doors fully.
Make sure the freezer door is supported, then remove the bottom hinge and remove the
door by pulling it downwards.
Make sure the fridge door is supported, then remove the middle hinge and remove the
door by pulling it downwards.
NOTE: there is a plastic spacer behind the centre hinge mounting plate.
Unscrew the top hinge pin and screw it into the threded hole on the left side of the door
opening.
Swap over the hinge inserts and blanking plugs on the top and bottom of both doors.
NOTE: the hinge insert on the bottom of the fridge door needs to face the opersite way,
see Fig 1.
Take the bottom hinge assembly, unscrew the hinge pin and door stop screw, then screw
them into the threded holes on the oppersit side of the bottom hinge plate.
Remove the 2 screws from the bottom left of the freezer door opening and screw them
into the 2 threded holes on the bottom right of the freezer door opening.
Swap the screw cover and 2 blanking plugs located at the bottom left of the fridge door
opening to the holes on the right side of the fridge door opening.
Locate the top hinge insert of the fridge door with the top hinge pin on the top left of the
fridge door opening. Then, supporting the door, fit the centre hinge assembly with plastic
spacer to the left side of the unit.
Locate the top hinge insert of the freezer door with the middle hinge pin on the left of the
freezer door opening. Then, supporting the door, fit the bottom hinge assembly to the
bottom left of the freezer door opening.
To restore the doors to shipping condition follow the above instructions transposing left
for right and right for left
FIG 1
Bottom of fridge door. Right hand Hinge Bottom of fridge door. Left hand Hinge
If the appliance is not operating correctly:
Please check the following points.
Is there a power failure? (Check by turning on a house light)
Has the fuse blown or has the circuit breaker tripped.
Has the door been closed correctly?
Check the thermostat has been set correctly.
Check the mains plug is seated in the wall socket correctly and the socket switch is on.
