12
On certain models, you can change the color of your
Travel Scooter by removing the colored plastic shroud
panel pieces and replacing them with one of the other
supplied sets. The panels are held in place by a hook and
loop reusable fastener. See Travel Scooter Features
Table (inside front cover).
To remove the shroud panel pieces:
1. Use your nger to locate the push hole behind each
shroud piece.
2. Push through the hole to separate the piece from the
Travel Scooter. See gure 11.
To remove the tiller console visor:
1. Gently pull the top of the visor away from the tiller
console, then slowly lift it up and away from the tiller
console. See gure 12.
To reinstall the shroud pieces, place each piece in its
appropriate location and push with slight pressure to
secure the reusable fastener.
NOTE: When installing the front and rear fender
panels, make sure the tab at the bottom of each panel is
inserted into the tab opening before securing the panel.
See gure 11.
