21
(See gure 17)
WARNING! Remove the key from the key switch
before adjusting the tiller or the seat. Never
attempt to adjust the tiller or the seat while the
Travel Scooter is in motion.
WARNING! Prior to operating the scooter, push
and pull on the tiller to ensure that the angle
adjustment mechanism is secure. Inspect the
tiller adjustment knob and the angle adjustment
mechanism to ensure that they are fully
engaged. If there is movement in the tiller,
check to make sure that the tiller adjustment
knob is fully tightened.
NOTE: In order to fully lower the tiller, you must rst remove
the seat and battery pack. Remove the seat by pulling it straight
up and off of the Travel Scooter.
The seat rotation lever, located on the right side of the seat base,
secures the seat into several positions. See gure 18.
1. Pull up on the seat rotation lever to disengage the seat.
2. Rotate the seat to the desired position.
3. Release the lever to secure the seat into place.
The armrest width can be adjusted inward or outward.
1. Loosen the armrest adjustment knobs. See gure 18.
2. Use the attached ring to pull and remove the detent pins.
3. Slide the armrests in or out to the desired width.
4. Align the adjustment holes on the seat frame and armrest,
then reinsert the detent pins.
5. Tighten the armrest adjustment knobs.
NOTE: Pivot the armrests upward to aid in getting onto and
off of your Travel Scooter.
The seat can be repositioned to different heights. See gure 19.
1. Remove the seat and battery pack from your Travel Scooter.
2. Use the attached ring to pull and remove the detent pin from
the lower seat post.
3. Raise or lower the upper seat post to the desired seat height.
4. While holding the upper seat post at that height, align the
adjustment holes of the upper and lower seat posts.
5. Fully insert the detent pin.
6. Replace the battery pack and seat.
