Jazzy Select Series www.pridemobility.com 19
Figure 8. The Jazzy Select 6 with Power Seat
REAR SHROUD
POWER SEAT ACTUATOR
MAIN CIRCUIT BREAKER
FRONT COVER
III. YOUR POWER CHAIR
FRONT
CASTER
WHEELS
REAR
CASTER
WHEEL
CONTROLLER CONNECTOR
