Jazzy Select Series www.pridemobility.com 21
Figure 10. Jazzy Select 6 with Power Seat Electrical Components
III. YOUR POWER CHAIR
CONTROLLER CONNECTOR
BATTERY CONNECTORS
MOTOR CONNECTORS
MAIN CIRCUIT BREAKER
BATTERY CONNECTORS
