VII. CARE AND MAINTENANCE
Figure 29. Battery Installation (Seat Removed for Clarity — Select 6 Shown)
CORRECT
CONNECTION
INCORRECT
CONNECTION
REAR SHROUD
FRONT COVER
SIDE COVER FRONT BATTERY
YELLOW
THUMBSCREWS
REAR
BATTERY
