Jazzy Select Series www.pridemobility.com 47
APPENDIX I – SPECIFICATIONS
Figure 30. Jazzy Select Dimensions and Ground Clearance
Figure 31. Jazzy Select 6 and Jazzy Select 6 with Power Seat Dimensions and Ground Clearance
41.75 in. (106.04 cm)
35.75 in. (90.8 cm)
20 in. (50.8 cm)
2.3125 in. – 4.3125 in.
(5.87 cm – 10.95 cm)
23.75 in. (60.32 cm)
0.75 in. (1.9 cm)
1.625 in. (4.13 cm)
1.875 in.
(4.76 cm)
0.75 in. (1.9 cm)
1.6875 in. (4.29 cm)
21.875 in. (55.56 cm)
41.5 in. (105.41 cm)
35.375 in. (89.85 cm)
2.3125 in. – 4.3125 in.
(5.87 cm – 10.95 cm)
23.5 in. (59.69 cm)
1.0625 in. (2.7 cm)
1.8125 in. (4.6 cm)
2 in.
(5.08 cm)
1.875 in. (4.76 cm)
1.875 in. (4.76 cm)
