SEAT
ARMRESTS
JOYSTICK
CONTROLLER
BODY SHROUD
Figure 1b. The Jet 1
FOOTREST
DRIVE WHEEL
ANTI-TIP WHEELS
CASTER WHEEL
SEAT ASSEMBLY
POWER BASE ASSEMBLY
Your Jet 1 has two main assemblies: the seat and the power base. See figures 1b and 2. Typically, the seating
assembly includes the armrests, seat, and joystick controller. Your Jet 1 seat may also have some optional accessories
attached to it, such as a basket, a cane/crutch holder, or a cup holder. See XI. Optional Accessories.
The power base is the heart of your Jet 1. The power base assembly includes a frame, two drive wheels, two anti-
tip wheels, two caster wheels, controller harnesses and a body shroud.
