18 www.pridemobility.com US Jet 1 ATS/Rev B/Jul03
Specifications
Suspension: Full suspension with Active-Trac
Drive Wheels: 14 in., pneumatic, center mounted (solid tires are optional)
Rear Casters: 8 in., solid, rear articulating
Anti-Tip: 6 in., solid, front mounted
Max. Speed: 4.5 mph
Brakes: Intelligent Braking, electronic regenerative, disc park brake
Ground Clearance: 3.5 in.
Turning Radius: 19.5 in.
Overall Size: Length: 38.5 in.
Width: 23 in.
Seating Options: Medium-back
Drive Train: Two motor, mid wheel
Batteries: Two 12-volt, NF-22 batteries
Range: Up to 25 miles
Battery Charger: Onboard
Electronics: 50-amp Dynamic controller
Weight Capacity: 250 lbs.
Base: 81 lbs.
Seat: 29 lbs.
Batteries: 38 lbs. each
Warranty: Five-year limited warranty on frame
One-year warranty on electronics
One-year warranty on drive motors
IV. THE JET 1
