III. YOUR POWER CHAIR
THE JET 3 ULTRA
The Jet 3 Ultra has two main assemblies: the seat and the power base. See figures 5 and 6. Typically, the seat
assembly includes the armrests, seatback, and seat base. The power base assembly includes two motor/brake
assemblies, two drive wheels, two anti-tip wheels, two caster wheels, two batteries, and the electrical components.
SEATBACK
CONTROLLER
ANTI-TIP WHEEL
DRIVE WHEEL
CASTER WHEEL
POWER BASE
ASSEMBLY
SEAT ASSEMBLY
FRONT RIGGING
(FOOT PLATFORM SHOWN)
SEAT BASE
ARMRESTS
Figure 5. The Jet 3 Ultra
