Jet 3 Ultra www.pridemobility.com 31
V. COMFORT ADJUSTMENTS
To adjust the anti-tip wheels:
1. Loosen bolt A. See figure 24.
2. Remove bolt B.
3. Raise or lower the anti-tip wheel. Each hole is 1/2 in.
(1.27 cm) apart.
4. Reinstall bolt B.
5. Tighten bolt A.
6. Raise or lower the other anti-tip wheel so that it is at
the same height.
ANTI-TIP WHEEL
BOLT B
BOLT A
Figure 24. Anti-tip Wheel Assembly
