22 www.pridemobility.com Jet 7
Figure 17. Removing Battery Well Frame Figure 18. Battery Well Frame
LOCATING PINS
V. DISASSEMBLY
Figure 19. Removing Front Frame
FRONT FRAME
FRAME
ASSEMBLY
HANDLE
Figure 20. Front Frame Assembly
LOCATING PIN
Figure 16. Removing Battery Boxes
