V. YOUR PRIDE LX
The Pride LX is a rear-wheel drive power chair that you can easily disassemble and fold for transportation or
storage. The two battery boxes sit on the battery tray.
SEAT
Figure 14. LX10 Assembled (LX11 and LX 12 are similar.)
CASTER WHEEL
CONTROLLER
ARMRESTS
SWING-AWAY
FOOTRESTS
SEATBACK
DRIVE WHEEL
FRONT BATTERY BOX
RIGHT MOTOR BRAKE ASSEMBLY
LEFT MOTOR
BRAKE ASSEMBLY
REAR BATTERY BOX
POSITIONING BELT
SEAT CANES
