Quantum Q6 Edge www.pridemobility.com 7
Battery charger for indoor use only.
Contains Lead.
II. SAFETY
Unlocked and in freewheel mode.
Locked and in drive mode.
Battery Set Configuration:
+ = Positive (Red) Terminal Post
- = Negative (Black) Terminal Post
Connect Red wires to Red Positive (+) Terminal Posts.
Connect Black wires to Black Negative (-) Terminal Posts.
EMI/RFI — This product has been tested and passed at an immunity level of 20 V/m.
Indicates electrical shock hazard.
Wire access point. For service use only.
Place unit on level ground and stand to one side when changing from drive mode to
freewheel mode or freewheel mode to drive mode.
To Next Page
