31
Sonic www.pridemobility.com
ARMREST WIDTH ADJUSTMENT
The armrest width can be adjusted inward or outward.
See figure 17A.
1. Remove the detent pins located near the adjustment
knobs.
2. Loosen the armrest adjustment knobs at the back of
the seat frame.
3. Slide the armrests in or out to the desired width.
4. Reinsert the detent pins through the adjustment holes
of both the seat frame and armrest frame.
5. Tighten the armrest adjustment knobs as required.
The armrests can also pivot upward to aid in getting onto
and off of your scooter.
VIII. COMFORT ADJUSTMENTS
Figure 17A. Armrest Width Adjustment
DETENT PIN
ARMREST ADJUSTMENT KNOB
