Pride Mobility Victory 9 - Page 43

Victory Series www.pridemobility.com 43
APPENDIX I - SPECIFICATIONS
22.25 in.
(56.5 cm)
3-Wheel: 45.25 in. (115 cm)
4-Wheel: 47 in. (119.38 cm)
3 in.
(7.62 cm)
35.75 in. (90.8 cm)
54 in. (137.16 cm)
4-Wheel Turning Radius
42 in. (106.68 cm)
3-Wheel Turning Radius
18 in.
(45.72 cm)
17 in.
(43.18 cm)
14.5 in.
(36.83 cm)
17.5 - 19 in.
(44.45 - 48.26 cm)
Figure 25. Victory 10 Dimensions
