5.1 Installation
5.1.1 Take out the wheelchair from the packing box and put it on the
ground. Push the backrest and footrest back and forth respectively
by two hands(figure 2). When you hear a click, the locating pins are
inserted into the positioning holes, and in this case, the chair frame
has been completely opened
5.1.2 Fold down the armrest forward(figure 4)
5.1.3 Put the controller on the armrest(figure 5). And then pull down
the tightening spanner on the controller to fasten the controller. (figure 6)
5.1.4 Turn over the wheelchair, press the stopper pins down to release
legs(figure 7) and pull out the anti-tipper until a location pin automatically
lock the anti-tipper(figure 8).
5.1.5 Take out the foam pads from the battery boxes, and then put the
two batteries separately into the right and left boxes(figure 9). Note that
the batteries should be fully inserted in the end(figure 10).
5.1.6 Fold down the footrest forward completely(figure 12).
5.1.7 Switch the motor lock levers on the motors to the “Electric” mode
(figure 11).
5.1.8 Now, your wheelchair has been completely assembled, and can be
used.
