Quantum 610 www.pridemobility.com 11
IV. ASSEMBLY
INITIAL ASSEMBLY
Your power chair may require some assembly either before initial use or after transportation. It may also require
disassembly to make some comfort adjustments. Figure 6 details those parts of the power chair that are designed
to be disassembled and assembled by an end user or by a qualifi ed carer before using the product or making
comfort adjustments.
NOTE: Any nylon insert lock nut removed during the disassembly or adjustment of the power chair must be
replaced with a new nut. Nylon insert lock nuts should not be reused as it may cause damage to the nylon
insert, resulting in a less secure fi t. Replacement nylon insert lock nuts are available at local hardware stores
or through your Quantum Rehab Dealer.
Figure 6. Quantum 610 Series Assembly View (Universal Mounting System Shown)
SEAT INSTALLATION
ARMREST ANGLE ADJUSTMENT
SEAT HEIGHT/ANGLE ADJUSTMENT
FOOT PLATFORM
ANGLE ADJUSTMENT
CONTROLLER POSITION
FOOT PLATFORM HEIGHT/DEPTH ADJUSTMENT
