30 www.pridemobility.com Quantum Q4
Figure 24. Battery Installation
BATTERY WIRING DIAGRAM LABEL
QUICK RELEASE
BATTERY
CONNECTORS
FRONT BATTERY
REAR BATTERY
FRONT COVER
RELEASE HANDLES
Battery Set Configuration:
+ = Positive (Red) Terminal Post
- = Negative (Black) Terminal Post
Connect Red wires to Red Positive (+) Terminal Posts.
Connect Black wires to Black Negative (-) Terminal Posts.
VII. CARE AND MAINTENANCE
