Section 5: Specifications
26
RMX500 RMX600
Working Width 60” 72”
Overall Width 67” 79”
Overall Length (Including Tail-Wheel)
94” 107”
Weight (with Front Guard) 570 lbs 729 lbs
High Blade Speed Tip
FPM (Feet Per Minute)
Ensures a clean cut.
12,469 FPM 14,963 FPM
Blades Heat Treated Alloy Steel
- Free Swing Blades
1-1/2” Bolt and Nut
1/2” x 3 1/2” x 22”
Heat Treated Alloy Steel -
Free swing blades
Deck Height
(underside of deck to bottom of skid)
8 3/8”
Deck Material Thickness 10 Gauge
Deck Design Fully welded for additional strength.
Shaped to discharge grass more effectively than other models.
Minimum Horsepower Rating Minimum Maximum
25 HP 40 HP
Minimum Maximum
40 HP 65 HP
Gearbox Vertical mount 90
o
with Spline Input and tapered
Spline Output with hub. 540 rpm PTO Driven
Gearbox 1:1:47 Cast Iron Housing
Vertical mount 90
o
with Spline Input and tapered
Spline output with hub. 540 rpm PTO Driven
Gearbox 1:1:46 Cast Iron Housing
Gearbox Oil SAE 85W-140EP
Oil Capacity 23 Oz (.68 Liters)
Cutting Height 1-3/4” - 12”
Cutting Capacity Grass, weeds and brush not to exceed 1" dia.
Safety Guards Protects against flying object hazards. Rubber (Front and Rear)
or Optional Chain Guard (Front and Rear).
Skids Provides sidewall reinforcement and full protection to bottom sidewall.
3/8” x 2” weld on.
Stump Jumper Allows mower to slide over obstructions while protecting the gearbox output shaft.
Oval Pan 1/4” thickness.
Driveline Slip clutch driveline offers convenience for continual work.
Driveline Safety Protection Shielded Series 4 PTO Driveline Shaft 29” with
1-3/8” 6-Spline and 2– Disk Slip Clutch
Tail-Wheel 4” x 8” x 15” Laminated Tire.
Heavy Duty Spindle on Tail-Wheel 1-1/2” Spindle gives the strength to protect tail-wheel assembly.
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE!
SAE 85W-140EP
Oil Capacity 33 Oz (.90 Liters)
Shielded Series 5 PTO Driveline Shaft 34” with
1-3/8” 6-Spline and 2– Disk Slip Clutch
1/2” x 4” x 26”
Heat Treated Alloy Steel
Free swing blades
RMX MODEL SPECIFICATIONS
