UK PLUG WIRING INSTRUCTIONS
The wires in the mains lead are coloured in accordance with the
following code:
BROWN - LIVE (L)
BLUE - NEUTRAL (N)
GREEN/YELLOW - EARTH (E)
As the colours of the wires in the mains lead of this appliance may not
correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:
• The BLUE wire is the NEUTRAL and must be connected to the terminal
which is marked with the letter N or coloured BLACK
• The BROWN wire is the LIVE and must be connected to the terminal that
is marked with the letter L or coloured RED.
• The wire which is coloured GREEN/YELLOW must be connected to the
terminal which is marked E or coloured GREEN or GREEN/YELLOW.
Always ensure that the cord grip is positioned and securely fastened.
WARNING: THIS APPLIANCE MUST BE EARTHED.
If a 13A (BS1363) fused plug is used it must be fitted with a 13A fuse. If
in doubt consult a qualified electrician.
WIRING FOR A 13AMP PLUG
13 AMP
LIVE
(BROWN)
EARTH
(GREEN & YELLOW)
NEUTRAL
(BLUE)
