CRX Model
Version no
000
BT Prime-Mover, Inc.
17
LON Manual 2005-08-15
Cylinder valve, hydraulic, flow control 7012 0.3
Cylinder, main piston (2 Techs) 7014 3.5
Cylinder, main housing (2 Techs) 7016 3.5
Cylinder, main bleeder screw, back-up ring, screw 7018 0.1
Cylinder, main piston cap (2 Techs) 7020 3.0
Cylinder, repack, square seal (2 Techs) (313665-971) 7022 3.0
Cylinder, main tee run 7024 0.3
Cylinder, free lift, center 7030 1.2
Cylinder, free lift valve, hydraulic flow control 7032 0.9
Cylinder, free lift piston (1 Tech) 7034 1.75
Cylinder, free lift housing (1 Tech) 7036 1.75
Cylinder, free lift ram housing cap 7038 1.5
Cylinder, repack, square seal (313665-969) 7040 1.75
Mast main Right hand or Left hand chain anchor block 7110 0.7
Mast main pulley, lift hose 7120 0.7
Mast, main spacer, pulley (2 Techs) 7130 1.0
Mast, main bearing, chain roller (2 Techs) 7140 1.1
Mast, main bearing, mast roller bottom, top, re-shim 7150 0.5
Mast main pin, pulley bracket, center ram 7160 0.6
Mast main spacer, pulley, center ram 7170 0.5
Mast main pulley, chain, center ram 7180 0.6
Mast, mast hose pulley free lift (2) 7185 0.5
Mast main stud, main frame roller 7190 0.5
Mast main sleeve, pulley 7200 0.6
Mast main bracket, formed standoff 7210 0.5
Mast, hose assembly, free lift, over pulley hose 7220 0.3
Mast, main anchor, chain, adjustment 7230 0.5
Mast main, chain, leaf 7240 0.6
Mast main, link, connecting 7250 0.2
Mast main, bolt, ram mounting (2 Techs) 7260 1.1
Mast main, adapter, hydraulic 7270 0.3
Mast, main hose assembly (313666-377) 7280 0.3
Mast, main hose assembly lift tractor to mast 7290 0.5
Auxiliary mast hose pulley free lift (2) 7295 0.06
Carriage weldment, fixed 7300 2.0
Group Operation Description LON Time
