RSX50 Model
Version no
001
BT Prime-Mover, Inc.
81
LON Manual 2005-08-15
RSX50 Model
Group Operation Description Lon Time
Transmission
Remove and Replace 1-001 2.0
Replace Axle Seal 1-002 3.0
Replace Drive Axle 1-003 3.0
Rebuild / Recondition 1-004 8.0
Replace Steer Bearing 1-005 2.2
Replace Drive Motor Brake Disc (includes adjusting) 1-010 1.5
Adjust Brakes 1-011 0.5
Replace Drive Tire 1-012 0.5
Replace Caster Brake Shoes (includes adjusting) 1-013 2.0
Adjust Caster Brake 1-014 0.5
Replace Brake Pedal 1-016 2.0
Electrical
Replace Horn 2-001 0.3
Replace Emergency Disconnect 2-002 0.8
Adjust Brake Switch 2-003 0.7
Replace Accessory Wiring Harness (OHG) 2-004 1.0
Replace Key Switch 2-005 1.0
Replace Brake Switch 2-006 0.7
Replace Lift Potentiometer 2-007 1.0
Replace Reach / Tilt / Sideshifter Potentiometer 2-008 1.0
Replace Horn Button 2-009 1.0
Replace Direction/speed Potentiometer 2-010 1.0
Replace Brake Transducer (includes adjusting) 2-011 0.7
Adjust Brake Transducer 2-014 0.7
Replace Drive Motor 2-015 1.5
Replace K11 / K13 Contactor 2-018 1.5
Replace Steer Tachometer 2-020 1.5
Replace Main Contactor 2-021 1.0
Replace Drive Motor Fan 2-024 0.7
Replace Lift Pump By-Pass Contactor 2-025 1.0
