Prime Tech WF08 - PRODUCT FEATURES AND SPECIFICATIONS; 12000 lbs Winch Overview; 12 V DC Line Speed and Amp Draw; 24 V DC Line Speed and Amp Draw

11
12000LBS FEATURES AND SPECIFICATIONS
Single Line Rated Pull 12000lb (5440kg)
Motor 12V 6.6hp/ 4.8kw, 24V 4.0hp/3.0kw,series wound
control Remote Switch, 12ft (3.7m) lead
Gear train 3 Stage Planetary
Gear reduction ration 187.2:1
Braking Action Automatic In-The-Drum
Cable 94ft of 3/8〞diameter (28m of 9.1mm diameter)
Main body Sealed
Effected protection 5600kg-5750kg
Fairlead 4-Way Roller Fairlead
Battery Leads 2gauge,72〞(1.83m)
Overall dimensions (L*W*H)20.4〞*6.3〞*8.6〞(537*160*218mm)
Mounting Bolt Pattern 10.00 ± 0.015〞*4.50±0.010〞(254*114.3mm)
12V DC LINE SPEED AND AMP DRAW(FIRST LAYER)
Line Pull (lbs./kg) Line Speed FPM(m/min) Motor(Amps)
0 33.3ft(10.3m) 85
4000(1810) 16.8ft(5.1m) 158
6000(2720) 12.8ft(3.9m) 231
8000(3630) 10.1ft(3.1m) 302
10000(4540) 8.8ft(2.7m) 371
12000(5440) 7.6ft(2.3m) 450
12300(5590) 0ft(0m) 200
24V LINE SPEEED AND AMP DRAW(FIRST LAYER)
Line Pull(lbs./kg) Line Speed FPM(m/min) Motor(Amps)
0 35.0ft(10.8m) 50
4000(1810) 18.5ft(5.6m) 130
6000(2720) 14.4ft(4.4m) 170
8000(3630) 11.5ft(3.5m) 210
10000(4540) 10.0ft(3.1m) 240
12000(5440) 8.9ft(2.7m) 280
12300(5590) 0ft(0m) 100
